SkyRC ARES PRO 540 V4 Brushless Motor 13.5T

SkyRC ARES PRO 540 V4 Brushless Motor 13.5T

The SkyRC ARES PRO 4 is a sensored competition motor that combines uncompromising control with explosive acceleration. The CNC-machined aluminum heatsink can, precision-balanced rotors, and premium bearings ensure consistent lap times from qualifiers to finals.

Thanks to its dual sensor ports, cable routing can be kept neat and space-saving. The housing is designed to be maintenance-friendly and modular: endbells, stator, rotor, and bearings can be quickly cleaned or replaced with standard RC tools. For on-track fine tuning, the timing can be easily adjusted directly on the motor.

Features:

ROAR-approved competition motor for 1/10 on-/offroad (Stock & Modified)

Advanced sensor technology for linear, cog-free power delivery

CNC-machined aluminum heatsink can for efficient heat dissipation

High-purity copper windings (up to 220 °C) & heat-resistant neodymium magnets (up to 150 °C)

Precision rotor, premium ball bearings & durable endbells

Finely adjustable timing

Fully disassemblable for service & setup

Technical Data:

Type: Brushless / Sensored SPEC

Turns: 13.5T

Timing: adjustable

Sensor ports: 2× (Dual-Port)

Can diameter: approx. 35.8 mm

Can length: approx. 52 mm (without shaft)

Shaft diameter / length: 3.175 mm

Weight: approx. 148 g

Approval: ROAR-approved

Application: 1/10 Stock & Modified (On-/Offroad)
